KB90 3 Group Volumetric
KB90 3 Group Volumetric

KB90 3 Group Volumetric

LMKB903GAV

Regular price $25,400.00 Save $-25,400.00
/


Only 0 items in stock!
KB90 3 Group Volumetric is considered a commercial item. Commercial items are not subject to the returns and exchange policy. If you have any concerns regarding the KB90 3 Group Volumetric's features, abilities, or fit please contact commercial equipment sales here.
Full Shipping Policies & Full Returns & Refund Policy

Highlights

The ultimate workflow machine, a new standard in high volume café performance.

The KB90 is the ultimate evolution of the Linea PB form. Designed to optimize the workflow for the barista in the world’s busiest bars by improving the ergonomics and features of the machine. The KB90 is named for our Board Chairman, Kent Bakke. 20 years ago, Kent imagined one of the most exciting new features of the KB90, the Straight-in Portafilter. Kent has always seen La Marzocco’s mission to create machines that make the lives of the barista easier and more efficient, and the KB90 embodies this philosophy.

Features

Straight In Portafilter

Designed to simplify the motions required to engage the portafilter and reduce the strain by 12 times on the barista for even greater performance and everyday usability. High volume coffee environments demand that a barista can work fast and efficiently to produce drinks during busiest periods of the day. The Straight-In Portafilter can noticeably mitigate the repetitive stress injuries occurring through its ease of action improving the natural workflow and output of barista.

Auto Steam Flush

After each extraction, a burst of steam from the steam boiler purges the brew path and is followed by a flush of hot water, keeping the group clean even during the busiest hours. This innovative function minimizes coffee residue in the group, and reduces the number of times baristas need to back flush during service.

Auto Brew Ratio with Drip Prediction

Precision scales incorporated into the drip tray improve beverage consistency by stopping the extraction based on mass. The machine uses an algorithm called Drip Prediction to improve shot accuracy and ease of dialing in.

Independent Boilers

Separate boilers for each group head allow barista to optimize temperature for individual coffees.

Technical Notes

Dual boiler system

Separate boilers optimize espresso brewing and steam production.

Independent brew boilers

Separate boilers for each group head allow barista to optimize temperature for individual coffees.

PID temperature controller

Allows you to electronically control coffee and steam boiler temperature.

Saturated group design

Ensure unsurpassed thermal stability, shot after shot.

Thermal stability system

Brew water is pre-heated before entering the boiler for increased temperature stability.

Ergonomics

Steam flush

Keeps the group clean with an automatic burst of steam and a flush of hot water between extractions.

pro touch steam wands

High performing steam wands that are cool to the touch.

easy rebuild steam valve

Engineered so the valve can be serviced directly from the front of the machine without needing to be removed.

hot water economizer

Enables you to fine-tune the tap water temperature for rinsing.

digital display

Intuitive programming makes it easy to adjust machine parameters.

barista lights

LED lighting allows you to focus on your extraction and the cup.



Specifications

specifications 2grp 3grp
Height (in) 20.75 20.75
Width (in) 32 41.5
Depth (in) 24.5 24.5
Weight (lbs) 170 223
Voltage (VAC, phase, Hz) 208-240, 1, 60 208-240, 1, 60
Amperage (A) 30 50
Element Wattage (W) 5400 7300
Coffee Boiler (liters) 1.3×2 1.3×3
Steam Boiler (liters) 7 11
Certifications UL-197, NSF-8, CAN/CSA-C22.2 No. 109



Dimensions

Height 20.75 in
Width 41.5 in
Depth 24.5 in
Cup Clearance N/A in
Weight 223 lbs

Electrical

Voltage 220 V
Amperage 50 A
Wattage 7300 W
Outlet Requirements 60Hz / 110V (Some Exceptions Apply)

Other Specifications

Boiler(s) Material Stainless Steel
Boiler Size 11 L
Certifications UL-197, NSF-8, CAN/CSA-C22.2 No. 109
Reservoir Size N/A L
Included Accessories

Warranty

Warranty Period 2 Year Manufacturer Warranty
Warranty Provider La Marzocco
Warranty Contact christopher@lamarzocco.com or (206) 258-2532 x2
